Two-Component Automatic PE Paint Spray Gun Paint-Saving Spray Gun

Model:: SGA-S2-PE

USD Unit Price:: 426

MOQ:: 1Pcs

Payment:: Cash on delivery

Delivery Time:: 1-7 days

Certification:: PatentCN203565238U

Inquire Online
Download

Cancel

PRODUCT FEATURES

Automatic PE gun used the Principle of manual type gun and combined with automation control,it satisfy with PE gun can be used for automated production lines,the application of manual principles ,combined with automation and control, high-volume flow of operations. Suitable for processing furniture, floor tiles,waistline and other products.

Each gun needs to carry two constant current modules,equipped with automatic control system,with lines or robot.

Product classification: Paint-saving spray gun

PRODUCT PARAMETER

All the data in the table are collected from CNISOO / CNSEIKO laboratory. The test fluid is tap water with PH = 7, the coating pressure is 1Bar, and the pipeline is directly connected. The atomized particle data is laser diffraction.

Model	SGA-S2-PE-10P	SGA-S2-PE-13P	SGA-S2-PE-15P	SGA-S2-PE-30P
Type of Feed	Pressure Feed Type(0.25MPa～0.6MPa)
Nozzle Diameter(mm)	1.0	1.3	1.5	3.0
Air pressure(MPa)	0.35～0.6
Air Consumption(l/min)	160～185
Liquid Output(l/min)	385～465
Pattern Width(mm)	135
Air Cap Model	PE-2/JAC-1/JAC-2
Air Hose Size(mm)	5×8mm Double Hose PTF 582
Liquid Hose Size(mm)	4×6mm Double Hose PTF 462
Weigh(g)	800
Equipment	For automatic type,it should be equipped with automatic production line,robot or other automatic machinery.And A series stainless steel pump supplies liquid.

Product application introduction

Spray guns are popular in the field of artificial spraying because of their lightness and excellent

atomization. Is widely used in electronics, electrical appliances, furniture, wood products, hardware, aerospace, automotive, daily necessities and other household products, smart product shells, model toys and other surface treatment processes.

Classic Application

Handicraft surface chrome/jewelry surface spraying

Shell chrome of mobile phone and life appliance such as light decoration accessory

Shoes heel spraying

Auto spraying
